CAT7 FTP Toolless RJ45 Field Termination plug

PREV: No previous article NEXT: CAT7 FTP Toolless RJ45 Field Termination Plug with lock

Specification
Ordering Information
Packing Information

DESIGN & MATERIALS

ANSI/TIA Category	CAT6/CAT6A/CAT7/CAT8
Type	RJ45
Shield	Shielded
Color	Gray/Orange/Blue
Housing Material	Metal
Contact Base Material	Copper
Contact Plating Material	Gold plated over Nickel
Thickness of Pin	3μ/6μ/15μ/30μ/50μ
IDC Material	Phosphor bronze
Wiring	T568A/T568B
Feature	Tool-free
Wire Gauge Supported	22-26AWG

ELECTRICAL & MECHANICAL DATA

Current Rating	1.5 amp max
Voltage Rating	250V AC max at 2 amps
Insulation Resistance	500 MΩ
Dielectric Withstanding Voltage	500 Volts AC
Termination Resistance	35mΩ
Cable to Plug tensile strength	20LBs(89N)min
Durability	500 mating cycles

Part Number Packing Qty. Packing
Mode N.W
(kg) G.W
(kg) Dimension
(mm)

MP-6-PB01
MP-6a-PB01
MP-7PB01
MP-8PB01 500PCS Carton Box 11 12 560*390*240

PUXIN Story

Ningbo Puxin Electronic Technology Co., Ltd. has established for more than 15 years, which is specialized in the production of integrated network cabling products and optic fiber products, including copper CAT5E, CAT6, CAT6A, CAT7, CAT8, such as keystone jack, patch panel, RJ45 connector, patch cord, and other related products.

As a China China CAT7 FTP Toolless RJ45 Field Termination plug manufacturer and China CAT7 FTP Toolless RJ45 Field Termination plug factory, Our company has advanced manufacturing equipment, testing equipment, and scientific and quality control methods. We have rich experience in manufacturing OEM and ODM products. At present, our products have been exported to Southeast Asia, South America, Australia, the Middle East, Europe, and other countries.

We sincerely look forward to working together with domestic and foreign merchants to create common development. Friends from all walks of life are welcome to visit, guide, and negotiate business.

About us

What Can We Offer?

Based on the high-grade and high-end market, our products meet international standards and are mainly exported to the United States, Europe, South Korea, Southeast Asia, South America and other countries.

Production Capacity

Advanced technology is employed to ensure data control of product materials.
Strict control is implemented at every stage of raw material procurement to ensure traceability.
Prior to production, specialized quality data is certified according to customer requirements to meet various quality and certification demands.

Customization Capability

Our R&D team has more than 10 years of experience in the production and design industry. We can accept OEM and ODM orders, you only need to provide customized sizes and shapes to enjoy professional customization services. Welcome to share your ideas with us and let us work together to make life more creative.

Timely Delivery

We can provide free samples to customers and complete orders within three days of communication. With a stable supply chain, we are able to accurately control production delivery time and ensure delivery quality.

Latest Updates

Provide you with the latest enterprise and industry news

Can the network cabinet add or reduce equipment according to actual needs? Network cabinets have high scalability and can add or remove equipment according to actual needs. Here are some key features about the adjustable devices in network cabinets: 1. Modular designNetwork ...

Does the use of network cabinets help us troubleshoot? The use of network cabinets is indeed beneficial for troubleshooting. Here are several key aspects to be introduced:1. Ordered wiringNetwork cabinets are usually equipped with a good cable management ...

Can the network cabinet automatically adjust the internal temperature? The network cabinet itself does not have the function of actively "automatically adjusting temperature", but it can achieve intelligent adjustment of internal temperature through integrated temperatur...

Are you ready to
cooperate with PUXIN?

Ningbo Puxin Electronic Technology Co., Ltd. is a professional supplier of electrical engineering and integrated wiring product research and development and manufacturing.

Quick Links

Products

Keep In Touch

No.43 of Xiaotuanpu Road, Guanhaiwei Town, Cixi Ningbo City, Zhejiang, China
fanny_fang@puxin-tech.com
8615924366333
gppuxin@gmail.com

Mobile web

Web Menu

Product Search

Language

Exit Menu

CAT7 FTP Toolless RJ45 Field Termination plug

Submit feedback

Part Number	Description
MP-6-PB01	Category 6 STPRJ45 Tool-free Field Termination Plug
MP-6a-PB01	Category 6a STP RJ45 Tool-free Field Termination Plug
MP-7PB01	Category 7 STP RJ45 Tool-free Field Termination Plug
MP-8PB01	Category 8 STP RJ45 Tool-free Field Termination Plug

Part Number	Packing Qty.	Packing Mode	N.W (kg)	G.W (kg)	Dimension (mm)
MP-6-PB01 MP-6a-PB01 MP-7PB01 MP-8PB01	500PCS	Carton Box	11	12	560390240
